enwitec Grid switch box for SMA inverters – 3x Sunny Island – 10013762
Mains switch box 3AC 230/400V 50Hz
– Connection fuse max. 250A
– All-pole disconnection, TN-S or TT system
– NO TN-C grid in the customer system Battery inverter:
Sunny Island 4.4M-12 / -13 from firmware version 1.00.xx.R
Sunny Island 6.0H-12 / -13 from firmware version 1.00.xx.R
Sunny Island 8.0H-12 / -13 from firmware version 1.00.xx.R Country availability: Germany, Switzerland – integrated HOME-MANAGER 2.0 For further technical information, please download the documentation. Note
Matchcode: 3PH_SMA.SI_BBDAP_125KVA_3PH_INT.HM_DACH_1.0
Article no.: 10013762 Compatible with: SMA
Phases: 3-phase
Mains disconnection: All-pole
Max. thermal throughput: 125 kW
Country code: Germany, Switzerland
NA protection: –
Source switch: –
Nominal voltage: 230/400V
Nominal frequency: 50/60 Hz
Short-circuit current: 10 kA
Back-up fuse: 250 A
Operating temperature range: -25°C to +40°C
Humidity: 5% to 95%
Protection class: II
Dimensions WxHxD: 600 x 800 x 300 mm
Weight: 36 kg
Housing: GRP
